Polyurethane (PU)

Extruded Polystyrene (XPS)

and Expanded Polystyrene (EPS)

   With a thickness range of 30mm to 100mm, allowing for tailored thermal and structural performance. Thermal Performance for 50mm Thickness (Approx. R-Values):

    •PU (Polyurethane) Core: R-12.0 to R-13.8

    •XPS (Extruded Polystyrene) Core: R-9.8

    •EPS (Expanded Polystyrene) Core: R-7.1 to R-8.7

  Note: R-values are industry approximations; exact performance depends on core formulation and density. Metal Facade Specifications:

    •Material:High-strength SS350GDgalvanized steel.

    •Coating: Standard polyester (PE) or advanced coatings (PVDF/HDP).

    •Coating Thickness:

        -Top Coat: 20–25 µm

        -Primer/Back Coat: 5–7 µm

  Applications: Widely used in storage facilities, all kinds poultry building, human inhabitancy , wall panel and roof panel ,etc.
